High mechanical strength
Excellent chloride corrosion resistance
Long service life
Oil & gas filtration
Marine engineering
Chemical separators
Chemical Composition
| C | Si | Mn | P | S | Ni | Cr | Mo | N | |
| ASTM A240/UNS S31803 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.03 | ≤0.02 | 4.5-6.5 | 21.0-23.0 | 2.5-3.5 | 0.08-0.20 |
| ASTMA240/UNS S32205 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.03 | ≤0.02 | 4.5-6.5 | 22.0-23.0 | 3.0-3.5 | 0.14-0.20 |
Surface Treatments
Passivated surface
Common Specifications
Grade: UNS S31803
Mesh: 5–200
Technical Data
Yield strength: ≥450 MPa
PREN: ~35
| UNS S32304 Wire Mesh | |||
| Mesh Count | Wire diameter(mm) | Aperture(mm) | Max width(m) |
| 10 | 0.60 | 1.94 | 1.60 |
| 20 | 0.40 | 0.87 | 1.60 |
| 30 | 0.30 | 0.55 | 1.60 |
| 40 | 0.23 | 0.40 | 1.60 |
| 50 | 0.20 | 0.31 | 1.60 |
| 60 | 0.15 | 0.27 | 1.60 |
| 70 | 0.12 | 0.24 | 1.60 |
| 80 | 0.13 | 0.19 | 1.60 |
| 90 | 0.12 | 0.16 | 1.60 |
| 100 | 0.10 | 0.15 | 1.60 |
| 120 | 0.09 | 0.12 | 1.60 |
| 150 | 0.063 | 0.11 | 1.60 |
| 180 | 0.053 | 0.01 | 1.60 |
| 200 | 0.053 | 0.07 | 1.60 |
Note: Special size and specification can be customized.
OEM Options
Precision cut panels
Custom mesh count
