Excellent electrical conductivity
High fatigue and wear resistance
Non-magnetic and corrosion resistant
Stable mesh aperture
Electrical shielding
Fine filtration
EMI/RFI shielding
Precision sieving
Surface Treatments
Natural bronze finish
Tin-plated (optional)
Common Specifications
Alloy: C51000 / C52100
Mesh: 10–300
Wire diameter: 0.03–0.8 mm
Technical Data
Conductivity: ~15% IACS
Melting point: ~950°C
| MESH | WIRE DIAMETER | APERTURE/OPENING | %OPEN AREA | ||
| INCH | MM | INCH | MM | ||
| 4X4 | 0.063 | 1.60 | 0.187 | 4.75 | 56.0 |
| 4X4 | 0.047 | 1.19 | 0.203 | 5.16 | 65.9 |
| 5X5 | 0.041 | 1.04 | 0.159 | 4.04 | 63.2 |
| 6X6 | 0.035 | 0.89 | 0.132 | 3.35 | 62.7 |
| 8X8 | 0.028 | 0.71 | 0.097 | 2.46 | 60.2 |
| 10X10 | 0.025 | 0.64 | 0.075 | 1.91 | 56.3 |
| 10X10 | 0.020 | 0.51 | 0.080 | 2.03 | 64.0 |
| 12X12 | 0.023 | 0.584 | 0.060 | 1.52 | 51.8 |
| 14X14 | 0.020 | 0.508 | 0.051 | 1.30 | 51.0 |
| 16X16 | 0.018 | 0.457 | 0.0445 | 1.13 | 50.7 |
| 18X18 | 0.017 | 0.432 | 0.0386 | 0.98 | 48.3 |
| 20X20 | 0.020 | 0.508 | 0.0300 | 0.76 | 36.0 |
| 20X20 | 0.016 | 0.406 | 0.0340 | 0.86 | 46.2 |
| 24X24 | 0.014 | 0.356 | 0.0277 | 0.70 | 44.2 |
| 30X30 | 0.013 | 0.330 | 0.0203 | 0.52 | 37.1 |
| 35X35 | 0.011 | 0.279 | 0.0176 | 0.45 | 37.9 |
| 40X40 | 0.010 | 0.254 | 0.0150 | 0.38 | 36.0 |
| 50X50 | 0.009 | 0.229 | 0.0110 | 0.28 | 30.3 |
| 50X50 | 0.008 | 0.203 | 0.0120 | 0.31 | 36.0 |
| 60X60 | 0.0075 | 0.191 | 0.0092 | 0.23 | 30.5 |
| 80X80 | 0.0065 | 0.165 | 0.0060 | 0.15 | 23.0 |
| 80X80 | 0.0055 | 0.140 | 0.0070 | 0.18 | 31.4 |
| 90X90 | 0.005 | 0.127 | 0.0061 | 0.16 | 30.1 |
| 100X100 | 0.0045 | 0.114 | 0.0055 | 0.14 | 30.3 |
| 100X100 | 0.004 | 0.102 | 0.0060 | 0.15 | 36.0 |
| 110X110 | 0.0040 | 0.1016 | 0.0051 | 0.1295 | 30.7 |
| 120X120 | 0.0037 | 0.0940 | 0.0064 | 0.1168 | 30.7 |
| 150X150 | 0.0026 | 0.0660 | 0.0041 | 0.1041 | 37.4 |
| 160X160 | 0.0025 | 0.0635 | 0.0038 | 0.0965 | 36.4 |
| 180X180 | 0.0023 | 0.0584 | 0.0033 | 0.0838 | 34.7 |
| 200X200 | 0.0021 | 0.0533 | 0.0029 | 0.0737 | 33.6 |
| 250X250 | 0.0016 | 0.0406 | 0.0024 | 0.0610 | 36.0 |
| 270X270 | 0.0016 | 0.0406 | 0.0021 | 0.0533 | 32.2 |
| 300X300 | 0.0051 | 0.0381 | 0.0018 | 0.0457 | 29.7 |
| 325X325 | 0.0014 | 0.0356 | 0.0017 | 0.0432 | 30.0 |
Note: Special size and specification can be customized.
OEM Options
Precision mesh tolerance
Custom width and length
