Outstanding oxidation resistance
Excellent high-temperature stability
Long service life in thermal environments
Low sulfur and carbon sensitivity
Furnace belts and screens
Heating element protection
Catalytic converter supports
High-temperature filtration
Surface Treatments
Bright annealed
Oxidation pre-treatment (optional)
Common Specifications
Alloy: FeCrAl (Kanthal equivalent)
Mesh: 5–200
Wire diameter: 0.05–1.5 mm
Technical Data
Max operating temperature: 1400°C
Density: ~7.1 g/cm³
| Mesh | Wire Gauge | Aperture (mm) | Wire Diameter (mm) | Roll Width (m) | Weight (kg/m2) |
| 8 (T) | 21 | 2.375 | 0.8 | 1.0 | 2.5 |
| 8 (T) | 22 | 2.475 | 0.7 | 1.0 | 1.84 |
| 10 (T) | 23 | 1.94 | 0.6 | 0.6 | 1.69 |
| 12 (T) | 24 | 1.557 | 0.559 | 1.0 | 1.8 |
| 17 (T) | 24 | 0.94 | 0.55 | 0.6 | 2.57 |
| 20 (P) | 33 | 1.02 | 0.25 | 1.0 | 0.587 |
| 20 (P) | 32 | 1.0 | 0.27 | 1.0 | 0.685 |
| 20 (P) | 30 | 0.97 | 0.30 | 1.0 | 0.846 |
| 25 (P) | 30 | 0.71 | 0.30 | 1.0 | 1.125 |
| 30 (P) | 38 | 0.69 | 0.15 | 1.0 | 0.30 |
| 34 (P) | 33 | 0.49 | 0.25 | 1.0 | 1.06 |
| 40 (P) | 35 | 0.425 | 0.21 | 1.0 | 0.83 |
| 40 (T) | 35 | 0.425 | 0.21 | 1.0 | 0.83 |
| 44 (T) | 35 | 0.367 | 0.21 | 1.0 | 0.88 |
| 60 (T) | 38 | 0.273 | 0.15 | 1.0 | 0.66 |
| 80 (P) | 43 | 0.227 | 0.09 | 1.0 | 0.324 |
Note: Special size and specification can be customized.
OEM Options
Custom alloy grades
Heat-resistant shaping
Roll or rigid mesh forms
