Portable and reusable fencing system
Fully welded mesh with tubular steel frame
Fast installation and dismantling
Compatible with concrete or plastic bases
Designed for Canadian construction and rental markets
OEM/ODM size, wire gauge, and branding options
Construction and demolition sites
Roadworks and infrastructure projects
Public events and crowd control
Temporary site security and access control
Residential and commercial developments
Hot-dip galvanized
Pre-galvanized (before welding)
Powder coated (optional)
| Fence | Specifications |
| Panel Height(mm) | 4ft, 6ft, 8ft |
| Panel Width(mm) | 8ft, 9ft, 9.5ft,10ft |
| Opening (mm) | 50x100mm,75x100mm,55x110mm,etc |
| Wire Diameter(mm) | 3mm,3.5mm,4mm |
| Frame square tube | 25x25mm, 30x30mm |
| Horizontal square rail | 20x20mm, 25x25mm |
| Fence feet | 863x89x8mm, 750x100x7mm |
| Top pins | Top clip to connect two panels together |
| Finishing of fence | Electric galvanized then powder or hot dipped galvanized then powder coated |
| Color | Blue, green, yellow,red,etc |
| Note: The fence can be customized according to your required if above specification is not satisfied with you. | |
Note: Special size and specification can be customized.
