Welded Wire Mesh Fence is manufactured by welding high-quality steel wires at each intersection to form a rigid and durable mesh panel or roll. It is widely used for perimeter fencing, security protection, and area separation in industrial, commercial, agricultural, and residential projects.
As an OEM/ODM welded wire mesh fence supplier, the fence can be customized in wire diameter, mesh size, panel dimensions, and surface treatment to meet different market standards and application requirements.
High Strength & Stability
Fully welded intersections provide strong structural integrity.
Uniform Mesh & Smooth Surface
Precise welding ensures consistent aperture and neat appearance.
Good Visibility & Ventilation
Open mesh structure allows airflow and clear sightlines.
Easy Installation
Compatible with various posts and fixing systems.
Wide Application Range
Suitable for both security and general-purpose fencing.
Customizable (OEM / ODM)
Size, coating, color, and packaging can be tailored.
Welded wire mesh fencing is commonly used in:
Industrial factories and warehouses
Construction sites and temporary fencing
Residential and commercial properties
Schools, parks, and public facilities
Agricultural fencing and animal enclosures
Highway, road, and railway fencing
Gardens and landscape fencing
Sports courts and playgrounds
Electro Galvanized (After or Before Welding)
Smooth finish, economical, suitable for mild environments.
Hot-Dip Galvanized (After Welding)
Thick zinc coating, excellent corrosion resistance.
Galvanized + PVC Coated
Enhanced durability and decorative appearance.
Powder Coated
Strong adhesion, uniform color, UV resistance.
Green (RAL 6005)
Black (RAL 9005)
Grey (RAL 7016)
Custom RAL colors available
Custom wire diameter & mesh size
Panel or roll supply
Custom coating thickness & colors
Private label packaging
Compliance with EN, ASTM, ISO standards
Bulk export & project-based production
| Mesh Opening | Wire Thickness | Panel Width | Number of Folds | Height |
| 55x200mm, 50x200mm, 50x100mm, 75x150mm, 50x150mm etc. | 3.0mm or 3.5mm or 4.0mm or 4.50mm or 5.00mm | 2.0m or 2.50m or 2.9m | 2 | 830mm |
| 2 | 1030mm | |||
| 2 | 1230mm | |||
| 2 | 1430mm | |||
| 3 | 1630mm | |||
| 3 | 1830mm | |||
| 4 | 2030mm | |||
| 4 | 2230mm | |||
| 4 | 2430mm |
| Post Type | Size | Thickness | Height |
| Round Post | 48mm, 60mm | 1.5mm, 2.0mm, 2.5mm, 3.0mm | 1.4m, 1.6m, 1.8m, 2.0m, 2.5m, 2.8m, 3.0m |
| Square post | 50x50mm, 60x60mm | 1.5mm, 2.0mm, 2.5mm, 3.0mm | 1.4m, 1.6m, 1.8m, 2.0m, 2.5m, 2.8m, 3.0m |
| Rectangular post | 40x60mm, 40x80mm | 1.5mm, 2.0mm, 2.5mm, 3.0mm | 1.4m, 1.6m, 1.8m, 2.0m, 2.5m, 2.8m, 3.0m |
| Peach post, | 50x70mm, 70x100mm | 1.2mm, 1.5mm | 1.4m, 1.6m, 1.8m, 2.0m, 2.5m, 2.8m, 3.0m |
| I post | 42x70mm | 1.2mm, 1.5mm, 2.0mm | 1.4m, 1.6m, 1.8m, 2.0m, 2.5m, 2.8m, 3.0m |
Note: Special size and specification can be customized.
